Optimizing File Upload Architecture with AWS S3 Presigned POST

In many systems, file uploads follow a familiar pattern:

1. A client sends the file to your application server.
2. The backend processes it (e.g., for validation or virus scanning).
3. Then it forwards the file to a cloud storage service like Amazon S3.

While this works, it’s highly inefficient. Your app becomes a middleman consuming bandwidth, CPU, and memory, just to pass files along.

Why This Is a Problem

This upload pattern:

• Consumes resources on your app server.
• Increases latency for users.
• Stresses your infrastructure (especially under load).
• Breaks down for large files, especially when you hit limits in intermediaries like API Gateway.

Let’s look at two common architectures where these problems show up.

Two Upload Architectures Compared

🔸 Architecture 1: Upload with Nginx

This is typical in smaller-scale deployments with a single server behind a reverse proxy.

Problems:

• Nginx must buffer the file in memory or disk (an exception can be thrown here).
• App still receives and processes the full payload.
• Memory and CPU are wasted just to forward the upload.

🔸 Architecture 2: Upload via API Gateway + Load Balancer

This setup is common in cloud-native apps using AWS infrastructure.

Problems:

• API Gateway limits uploads to 10 MB max per request.
• Both ALB and your app must handle the file payload.
• This creates bottlenecks and risks timeouts.

✅ The Solution: Presigned POST to S3

Instead of routing uploads through your backend, you can let clients upload directly to S3, securely, using a presigned POST policy.

How It Works

1. The client asks your backend for a signed upload policy.
2. Your backend returns a temporary URL and form fields.
3. The client uploads the file directly to S3 using multipart/form-data.

Benefits of Presigned Uploads

• 🚀 Bypass Infrastructure: No more file handling by Nginx, ALB, or API Gateway.
• 📉 Reduce Server Load: No memory or CPU usage from streaming file data.
• ⏱️ Improve Latency: Fewer hops and no buffering.
• 💡 Avoid Limits: Works around API Gateway’s 10MB payload cap.
• 🔐 Secure: You control what, where, and for how long uploads are allowed.

Example Server-Side implementation

import { Injectable } from '@nestjs/common';
import { S3Client } from '@aws-sdk/client-s3';
import { createPresignedPost } from '@aws-sdk/s3-presigned-post';

@Injectable()
export class S3Service {

  public getPresignedPostPolicy(
    filename: string,
    bucketConfig: S3BucketResourceConfig,
    contentType?: string
  ): Promise<{ url: string; fields: Record<string, string> }> {
    const expiresInSeconds = 600; // Default 10 minutes
    const maxSizeBytes = 150 * 1024 * 1024; // Default 150 MB

    const s3ClientConfig: S3ClientConfig = {
      region: bucketConfig.region
    };

    return createPresignedPost(new S3Client(s3ClientConfig), {
      Bucket: bucketConfig.name,
      Key: filename,
      Conditions: [
        ['content-length-range', 0, maxSizeBytes],
        ['starts-with', '$Content-Type', contentType || '']
      ],
      Fields: {
        ...(contentType && { 'Content-Type': contentType })
      },
      Expires: expiresInSeconds
    });
  }

}

Example Client Implementation

Here’s how a client might perform the upload:

import axios from 'axios';

async function uploadFile(file: File) {
  // Step 1: Get the presigned policy
  const res = await axios.get('/api/get-presigned-policy', {
    params: {
      filename: file.name,
      contentType: file.type,
    },
  });

  const { url, fields } = res.data;

  // Step 2: Prepare the upload form
  const formData = new FormData();
  Object.entries(fields).forEach(([key, val]) => formData.append(key, val as string));
  formData.append('file', file); // must be last

  // Step 3: Upload to S3
  const uploadRes = await axios.post(url, formData, {
    headers: { 'Content-Type': 'multipart/form-data' },
  });

  if (uploadRes.status === 204) {
    console.log('Upload successful');
  } else {
    console.error('Upload failed');
  }
}

When Should You Use Presigned POST?

• When handling large file uploads.
• When deploying behind API Gateway.
• When you want to scale uploads without scaling your backend.
• When you want better performance and lower infrastructure costs.

Summary

If you’re still uploading files through your backend, you’re likely wasting resources, risking timeouts, and introducing unnecessary complexity.

Presigned POST policies in AWS S3 offer a better approach:

• Simple to implement.
• Secure and time-limited.
• Scalable and resilient.

Offload uploads to your storage layer, which is where they belong, and keep your app fast, simple, and maintainable.

More info about the AWS feature

• Browser-Based Uploads Using POST (AWS Signature Version 4
• POST Policy - Amazon Simple Storage Service
• Example: Browser-Based Upload using HTTP POST (Using AWS Signature Version 4)
